BIM Services
Staff BIM Managers and BIM Coordinators
Multiple BIM Managers and Coordinators on staff, with the following capabilities:
- MEP Fabrication Database creation and management
- Autodesk Construction Cloud model management
- Consistent and repeatable project setups to avoid reinventing the wheel every project
- Multi-discipline and trade contractor BIM coordination through all phases of the project
Multi-Discipline BIM Designers
BIM design completed in Revit, allowing models at any LOD level for all disciplines/trades in your project.
- Process/Mechanical Piping
- Plumbing
- Dry Mech/HVAC
- Electrical / Controls
- Structural
Fully Integrated BIM Design
Our team is highly experienced and used to collaborating internally, as well as, with multiple design contractors working on the same project, through a shared ACC project. We have the capability to manage / coordinate the interaction via our in-house BIM Coordinators, but are also ready to support projects where the client and/or another lead team are doing the coordination.
Experience with Clash Detection / Resolution from Federated Model
We use the federated model to review designs to resolve / eliminate clashes. If reality capture / 3D scanning is being done concurrent with design (for new designs in existing facilities), we can load the scan files into the federated model to ensure clash-free design with the existing construction.
BIM Services for Issued for Fabrication (IFF)
We partner with clients and trade contractors to deliver full Issued for Fabrication (IFF) BIM detailing up through LOD400/500 and can provide all necessary fabrication drawings for trade contractors to build from.
- Production/fabrication piping isometrics
- Ductwork ISO spool drawings and .MAJ files
- Full fabrication drawings for all other disciplines
- Accurate BOQs/BOOMs generated from MEP Fabrication Parts
We use the federated model to review designs to resolve / eliminate clashes. If reality capture / 3D scanning is being done concurrent with design (for new designs in existing facilities), we can load the scan files into the federated model to ensure clash-free design with the existing construction.
We can partner directly with fabrication contractors to do IFF-level detailing and fabrication drawing production to facilitate pre-fabrication. On projects where we did the initial design, this is already set up into our design model to use the MEP Fabrication Parts specs.
When the trade contractor is awarded the project from another client / design team, we will build/modify fabrication specs to match the client specs and quickly develop the model from whatever point it was turned over into fully clash-free and fabrication ready.
